Technical Specifications
| Lead Mode |
5 Leads (I, II, III, AVR, AVL,AVF, V) |
| Gain | 2.5mm/mV, 5.0mm/mV, 10mm/mV, 20mm/mV |
| Heart Rate |
15-300 BPM (Adult); 15-350 BPM (Neonatal) |
| Resolution | 1 BPM |
| Accuracy |
+1% |
|
Sensitivity |
>200 uV(Peak to peak) |
| ST measurement range | -2.0 - +2.0 mV |
|
Accuracy |
-0.8mV-+0.8mV: +0.02mV or +10%, which is greater |
| Sweep speed |
12.5 mm/s, 25mm/s, 50mm/s |
|
Bandwidth |
|
NIBP
|
Method |
Oscillometry |
| Measure mode | Manual, Auto, STAT |
|
Unit |
mmHg, kPa |
|
Measure and alarm range |
0 - 50°C |
|
AduIt Mode |
|
|
Pediatric Mode |
|
| Neonatal Mode |
|
|
Resolution |
1mmHg |
| Accuracy |
+5mmHg |
TEMP
|
Measure and Alarm Range |
0 - 50°C |
|
Resolution |
0.1°C |
| Accuracy | +0.1°C |
RESP
|
Method |
Impedance between RA-LL or RALA |
|
Measurement Range |
|
|
Resolution |
1 BrPM |
|
Accuracy |
+2 BrPM |
Standard Configuration
|
Main Unit |
1 |
|
5-lead ECG cable |
1 |
|
Disposable ECG Electrode |
5 |
|
Adult Spo2 probe |
1 |
|
Adult NIBP cuff |
1 |
|
NIBP extension tube |
1 |
|
Temperature probe |
1 |
|
Power Cable |
1 |
|
User Manual(CD) |
1 |
|
Fuse |
3 |
SPO2
|
Measuring Range |
0 - 100 % |
|
Resolution |
1% |
|
Accuracy |
70% - 100% (+2 %) |
|
Pulse Rate |
20-250 BPM |
|
Resolution |
1 BPM |
|
Accuracy |
+3 BPM |
Standard Parameters
- ECG
- RESP
- TEMP
- NIBP
- SPO2
- PR
Optinal Parameters
- Recorder ( Printer)
- Central monitoring system
- Dual IBP
- Etco2
- 12-lead ECG;
- Nellcor SpO2;
- Sun Tech NIBP
Packing
|
Single package size |
37“28“36cm |
|
Single gross weight |
4.5 KG |
|
4 unit per carton, package size |
58*39*75cm, total gross weight 20 KG |
