CONTEC 3 Channel ECG Machine 300G

Name: CONTEC 3 Channel ECG Machine 300G
Brand: CONTEC
SKU: ECG-CTC-100-G
Availability: InStock
Rating: 5.00 (1 reviews)

Brand: CONTEC

Rated 5.00 out of 5 based on 1 customer rating

Original price was: 53,000.00 ₹.Current price is: 22,800.00 ₹.Piece

exclusive of all taxes

Screen Display: Features a 2.83-inch color LCD with a 320×240 resolution, ensuring clear visibility of ECG waveforms and device status.
User Interface: Combines a touchscreen with functional keys, offering an intuitive and effortless user experience.
Advanced Signal Processing: Employs state-of-the-art digital technology to capture high-precision ECG waveforms while incorporating noise reduction filters for improved accuracy.
Enhanced Digital Filtering: Eliminates baseline drift without distorting ECG signals, ensuring a precise and reliable reading.
Multiple Display Options: Users can choose from 3, 6, or 12-lead views on a single screen, along with real-time monitoring of sensitivity, paper speed, and filter settings.
High-Resolution Printing: Equipped with an 8-dot/mm thermal printing mechanism that requires no manual adjustments and supports recording frequencies up to 150 Hz.
Automated Analysis & Diagnosis: Instantly evaluates key ECG parameters such as heart rate, P-R interval, and QRS duration, providing diagnostic insights to assist medical professionals.
Data Storage Capability: Supports SD card storage for archiving up to 100 cases, allowing easy access and analysis of historical records.

Original price was: 53,000.00 ₹.Current price is: 22,800.00 ₹.Piece

Check Availability At

Compare

Lead	Standard 12 leads
Acquisition Mode	Simultaneous 12 leads acquisition
Measurement Range	±5mVpp
Input circuit	Floating; Protection circuit against Defibrillator effect
Input Impedance	250ΜΩ
Input circuit current	<0.05μA
Record mode	Automatic: 3CH 4+1R, 3CH 4, 3CHx2+2CHx3,3CHx2+2CHx3+1R,6CHX2; Manual: 3CH, 2CH, 3CH-OR, 2CH+1R; Rhythm: Any lead selectable.
Filter	EMG Filter: 25 Hz / 30 Hz / 40Hz/75 Hz / 100 Hz / 150Hz DFT Filter: 0.05 Hz/ 0.15 Hz AC Filter: 50 Hz / 60Hz
CMRR	>100dB
Patient leak current	<10μA (220V-240V)
Frequency Response	0.05Hz-150Hz (-3dB)
Sensitivity	2.5mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV (error:±5%)
Anti-baseline Drift	Automatic
Time constant	≥3.2s
Noise level	<15μVp-p
Paper speed	12.5 mm/s, 25 mm/s, 50 mm/s
Recording mode	Thermal printing system
Paper specification	Roll 80mmx20M
Safety Standard	IEC I/CF
Sample Rate	Normal: 1000sps/channel
Power Supply	AC: 100~240V, 50/60Hz, 30VA~100VA DC: 14.8V/2200mAh, built-in lithium battery
